Provides the default 1 byte or 2 byte DCCL ID codec. More...

#include <dccl/field_codec_id.h>

Inheritance diagram for dccl::DefaultIdentifierCodec:

[legend]

Protected Member Functions
virtual Bitset	encode ()
	Encode an empty field. More...

virtual Bitset	encode (const uint32 &wire_value)
	Encode a non-empty field. More...

virtual uint32	decode (Bitset *bits)
	Decode a field. If the field is empty (i.e. was encoded using the zero-argument encode()), throw NullValueException to indicate this. More...

virtual unsigned	size ()
	Calculate the size (in bits) of an empty field. More...

virtual unsigned	size (const uint32 &wire_value)
	Calculate the size (in bits) of a non-empty field. More...

virtual unsigned	max_size ()
	Calculate maximum size of the field in bits. More...

virtual unsigned	min_size ()
	Calculate minimum size of the field in bits. More...

virtual void	validate ()
	Validate a field. Use require() inside your overloaded validate() to assert requirements or throw Exceptions directly as needed.

Protected Member Functions inherited from dccl::FieldCodecBase
dccl::DCCLFieldOptions	dccl_field_options () const
	Get the DCCL field option extension value for the current field. More...

void	require (bool b, const std::string &description)
	Essentially an assertion to be used in the validate() virtual method. More...

bool	use_required ()
	Whether to use the required or optional encoding.

virtual std::string	info ()
	Write field specific information (in addition to general information such as sizes that are automatically written by this class for all fields. More...

virtual void	any_encode_repeated (Bitset *bits, const std::vector< boost::any > &wire_values)

virtual void	any_decode_repeated (Bitset repeated_bits, std::vector< boost::any > field_values)

virtual void	any_pre_encode_repeated (std::vector< boost::any > *wire_values, const std::vector< boost::any > &field_values)

virtual void	any_post_decode_repeated (const std::vector< boost::any > &wire_values, std::vector< boost::any > *field_values)

virtual unsigned	any_size_repeated (const std::vector< boost::any > &wire_values)

virtual unsigned	max_size_repeated ()

virtual unsigned	min_size_repeated ()

Additional Inherited Members
Public Types inherited from dccl::TypedFieldCodec< uint32 >
typedef uint32	wire_type

typedef uint32	field_type

Public Member Functions inherited from dccl::FieldCodecSelector< uint32, uint32 >
virtual uint32	pre_encode (const uint32 &field_value)=0
	Convert from the FieldType representation (used in the Google Protobuf message) to the WireType representation (used with encode() and decode(), i.e. "on the wire"). More...

virtual uint32	post_decode (const uint32 &wire_value)=0
	Convert from the WireType representation (used with encode() and decode(), i.e. "on the wire") to the FieldType representation (used in the Google Protobuf message). More...

Public Member Functions inherited from dccl::FieldCodecBase
	FieldCodecBase ()

virtual	~FieldCodecBase ()

void	base_encode (Bitset *bits, const google::protobuf::Message &msg, MessagePart part, bool strict)
	Encode this part (body or head) of the base message. More...

void	base_size (unsigned *bit_size, const google::protobuf::Message &msg, MessagePart part)
	Calculate the size (in bits) of a part of the base message when it is encoded. More...

void	base_decode (Bitset bits, google::protobuf::Message msg, MessagePart part)
	Decode part of a message. More...

void	base_max_size (unsigned bit_size, const google::protobuf::Descriptor desc, MessagePart part)
	Calculate the maximum size of a message given its Descriptor alone (no data) More...

void	base_min_size (unsigned bit_size, const google::protobuf::Descriptor desc, MessagePart part)
	Calculate the minimum size of a message given its Descriptor alone (no data) More...

void	base_validate (const google::protobuf::Descriptor *desc, MessagePart part)
	Validate this part of the message to make sure all required extensions are set. More...

void	base_info (std::ostream os, const google::protobuf::Descriptor desc, MessagePart part)
	Get human readable information (size of fields, etc.) about this part of the DCCL message. More...

void	field_pre_encode (boost::any *wire_value, const boost::any &field_value)
	Pre-encodes a non-repeated (i.e. optional or required) field by converting the FieldType representation (the Google Protobuf representation) into the WireType representation (the type used in the encoded DCCL message). This allows for type-converting codecs. More...

void	field_pre_encode_repeated (std::vector< boost::any > *wire_values, const std::vector< boost::any > &field_values)
	Pre-encodes a repeated field. More...

void	field_encode (Bitset bits, const boost::any &field_value, const google::protobuf::FieldDescriptor field)
	Encode a non-repeated field. More...

void	field_encode_repeated (Bitset bits, const std::vector< boost::any > &field_values, const google::protobuf::FieldDescriptor field)
	Encode a repeated field. More...

void	field_size (unsigned bit_size, const boost::any &field_value, const google::protobuf::FieldDescriptor field)
	Calculate the size of a field. More...

void	field_size_repeated (unsigned bit_size, const std::vector< boost::any > &field_values, const google::protobuf::FieldDescriptor field)
	Calculate the size of a repeated field. More...

void	field_decode (Bitset bits, boost::any field_value, const google::protobuf::FieldDescriptor *field)
	Decode a non-repeated field. More...

void	field_decode_repeated (Bitset bits, std::vector< boost::any > field_values, const google::protobuf::FieldDescriptor *field)
	Decode a repeated field. More...

void	field_post_decode (const boost::any &wire_value, boost::any *field_value)
	Post-decodes a non-repeated (i.e. optional or required) field by converting the WireType (the type used in the encoded DCCL message) representation into the FieldType representation (the Google Protobuf representation). This allows for type-converting codecs. More...

void	field_post_decode_repeated (const std::vector< boost::any > &wire_values, std::vector< boost::any > *field_values)
	Post-decodes a repeated field. More...

void	field_max_size (unsigned bit_size, const google::protobuf::FieldDescriptor field)
	Calculate the upper bound on this field's size (in bits) More...

void	field_min_size (unsigned bit_size, const google::protobuf::FieldDescriptor field)
	Calculate the lower bound on this field's size (in bits) More...

void	field_validate (bool b, const google::protobuf::FieldDescriptor field)
	Validate this field, checking that all required option extensions are set (e.g. (dccl.field).max and (dccl.field).min for arithmetic codecs) More...

void	field_info (std::ostream os, const google::protobuf::FieldDescriptor field)
	Write human readable information about the field and its bounds to the provided stream. More...

std::string	name () const
	the name of the codec used to identifier it in the .proto custom option extension

google::protobuf::FieldDescriptor::Type	field_type () const
	the type exposed to the user in the original and decoded Protobuf messages More...

google::protobuf::FieldDescriptor::CppType	wire_type () const
	the C++ type used "on the wire". This is the type visible after pre_encode and before post_decode functions are called. More...

const google::protobuf::FieldDescriptor *	this_field () const
	Returns the FieldDescriptor (field schema meta-data) for this field. More...

void	set_force_use_required (bool force_required=true)
	Force the codec to always use the "required" field encoding, regardless of the FieldDescriptor setting. Useful when wrapping this codec in another that handles optional and repeated fields.

Static Public Member Functions inherited from dccl::FieldCodecBase
static const google::protobuf::Descriptor *	this_descriptor ()
	Returns the Descriptor (message schema meta-data) for the immediate parent Message. More...

static const google::protobuf::Message *	root_message ()

static bool	has_codec_group ()

static std::string	codec_group (const google::protobuf::Descriptor *desc)

static std::string	codec_group ()

static int	codec_version ()

static MessagePart	part ()
	the part of the message currently being encoded (head or body).

static bool	strict ()

Detailed Description

Provides the default 1 byte or 2 byte DCCL ID codec.

Definition at line 27 of file field_codec_id.h.

Member Function Documentation

◆ decode()

dccl::uint32 dccl::DefaultIdentifierCodec::decode ( Bitset * bits )

protectedvirtual

Decode a field. If the field is empty (i.e. was encoded using the zero-argument encode()), throw NullValueException to indicate this.

Parameters

bits	Bits to use for decoding.

Returns: the decoded value.

Implements dccl::TypedFieldCodec< uint32 >.

Definition at line 51 of file field_codec_id.cpp.

◆ encode() [1/2]

dccl::Bitset dccl::DefaultIdentifierCodec::encode ( )

protectedvirtual

Encode an empty field.

Returns: Bits represented the encoded field.

Implements dccl::TypedFieldCodec< uint32 >.

Definition at line 28 of file field_codec_id.cpp.

◆ encode() [2/2]

dccl::Bitset dccl::DefaultIdentifierCodec::encode ( const uint32 & wire_value )

protectedvirtual

Encode a non-empty field.

Parameters

wire_value Value to encode.

Returns: Bits represented the encoded field.

Implements dccl::TypedFieldCodec< uint32 >.

Definition at line 33 of file field_codec_id.cpp.

◆ max_size()

unsigned dccl::DefaultIdentifierCodec::max_size ( )

protectedvirtual

Calculate maximum size of the field in bits.

Returns: Maximum size of this field (in bits).

Implements dccl::FieldCodecBase.

Definition at line 91 of file field_codec_id.cpp.

◆ min_size()

unsigned dccl::DefaultIdentifierCodec::min_size ( )

protectedvirtual

Calculate minimum size of the field in bits.

Returns: Minimum size of this field (in bits).

Implements dccl::FieldCodecBase.

Definition at line 96 of file field_codec_id.cpp.

◆ size() [1/2]

unsigned dccl::DefaultIdentifierCodec::size ( )

protectedvirtual

Calculate the size (in bits) of an empty field.

Returns: the size (in bits) of the empty field.

Implements dccl::TypedFieldCodec< uint32 >.

Definition at line 70 of file field_codec_id.cpp.

◆ size() [2/2]

unsigned dccl::DefaultIdentifierCodec::size ( const uint32 & wire_value )

protectedvirtual

Calculate the size (in bits) of a non-empty field.

Parameters

wire_value Value to use when calculating the size of the field. If calculating the size requires encoding the field completely, cache the encoded value for a likely future call to encode() for the same wire_value.

Returns: the size (in bits) of the field.

Implements dccl::TypedFieldCodec< uint32 >.

Definition at line 75 of file field_codec_id.cpp.

The documentation for this class was generated from the following files:

dccl/field_codec_id.h
src/field_codec_id.cpp
